Technical parameter
&Maxcswing over bed：1250mm
&Ma.swing over gap：1400mm
&Max.swing over cross slide：680mm
&Center distance：6000mm
&Width of bed：600mm
&Spindle hole：105mm
&Spindle tapor：120mm 锥度1:16
&Spindle speeds：7-720r/min
&Metric threads mm：1-240（52）mm
&inch threads TPI：1-14（26）mm
&Moudle threads mm:0.5-120 (53)mm
&Diaretra threads DP：1-28（24）mm
&Longitudinal feeds range：0.1-24.3mm/r
&Cross feed range：0.05-12.15mm/r
&Rapid feed:long'cross：4000/2000
&Tool section：32*32
&Cross slide travel：430mm
&Compound rest travel：200mm
&Sleeve diameter：100mm
&Sleeve taper：morse 6
&Sleeve travel：240
&MOTOR：680
&Main motor：11kw
&Rapid feed motor：1.1kw
&Length：7200mm
&Width：1500mm
&Height：1830mm
&Net weight：4.6/4.9/5.3/6.1/6.9/7.7T
