CW61125(600Rail)

Technical parameter

&Swing over bed：1250mm

&Maximum rotation diameter of the tool holder：930mm

&Maximum workpiece length：7000/8000/9000mm

&Maximum turning length:6850/7850/8850mm

&Main spindle inner hole diameter:Ф105

&Spindle hole front end taper:120#

&Top taper:mores 6

&Range of speed levels:18、7.5-720

&Number of vertical and horizontal feed rates：64

&Bed saddle moves quictly ：4000

&Maximum lateral travel of the lower tool holder：390mm

&Maximum stroke of upper tool hoider：200

&Tail socket diameter：Ф100

&Tail seat sleeve stroke：250

&Tailstock sleeve tapered hole：mores 6

&Main motor power：11KW

&Fast motor power:1.1KW

&Bed quide rail width:600mm

&Machine weight:6500/7000/7500kg

&Machine tool contour dimensions:8200/9200/10200*1550*1570mm
