CW61100(600Rail)

Technical parameter

swing over bed：1000mm

&Maximum rotation diameter of the tool holder：680mm

&Maximum workpiece length：3000/4000/5000mm

&Maximum turning length:2850/3850/4850mm

&Main spindle inner hole diameter:Ф105

&Spindle hole front end taper:120#

&Top taper:mores 6

&Range of speed levels:18、7.5-720

&Number of vertical and horizontal feed rates：64

&Bed saddle moves quictly ：4000mm/min

&Maximum lateral travel of the lower tool holder：390mm

&Maximum stroke of upper tool hoider：200

&Tail socket diameter：Ф100

&Tail seat sleeve stroke：250mm

&Tailstock sleeve tapered hole：mores 6

&Main motor power：11KW

&Fast motor power:1.1KW

&Bed quide rail width:600mm

&Machine weight:5000/5500/6000kg

&Machine tool contour dimensions:5200/6200/7200*1550*1570mm

More details, pls contact
