CW6180(600Rail)

Technical parameter

&swing over bed：800mm

&Maximum rotation diameter of the tool holder：180mm

&Maximum workpiece length：1000/1500/2000mm

&Maximum turning length:850/1350/1850mm

&Main spindle inner hole diameter:Ф105

&Spindle hole front end taper:120#

&Top taper:mores 6

&Range of speed levels:18、7.5-720

&Number of vertical and horizontal feed rates：64

&Bed saddle moves quictly ：4000

&Maximum lateral travel of the lower tool holder：390mm

&Maximum stroke of upper tool hoider：200

&Tail socket diameter：Ф100

&Tail seat sleeve stroke：250

&Tailstock sleeve tapered hole：mores 6

&Main motor power：11KW

&Fast motor power:1.1KW

&Bed quide rail width:600

&Machine weight:3500/3800/4000

&Machine tool contour dimensions:3100/3600/4200*1550*1570
