Technical parameter
&Max.swing over bed:630mm
&Max. turning diameter on the toot holder:350mm
&Max. workpiece length:1350/1850/2850/3850/4850mm
&Max.swing over gap:830mm
&Saddle effective width:300mm
&Bed rail width:550mm
&Spindle end code:C11
&Spindle through hole diareter:100mm
&Spindle front end taper:1:20/120mm
&Spindle speeds:7.5-1000mm
&Spindle speed series:18mm
&Vertical and horizontal feed amount range:64:0.1-24.32mm
&Transverse longitudinal feed ratio:1.0/2.0mm
&Screw pitch:12mm
&Metric threads mm:50;1-240
&Metric threads mm:26;14-1
&Skate fast moving speed:4000mm
&Lower horizontal travet of the lower tood hoider:440mm
&Upper turret maximum stroke:200mm
&Arbor cross section:32mm
&Sleeve diameter:100mm
&Sleeve travel:250mm
&Tailstock sleeve taper:Morse 6
&Main motor powrer:11mm
&Machine weight:3700/4200/4700/580016800
&Machine length:3725/4225/5225/6275/7275
&Machine width:1393
