CW61100(550Rail)

Technical parameter

&Swing over bed：1000mm

&Maximum rotation diameter of the tool holder：720mm

&Maximum workpiece length：4000/5000mm

&Maximum turning length：3850/4850mm

&Main spindle inner hole diameter：Ф105

&Spindle hole front end taper：120#

&Top taper：Mohs6

&Range of speed levets：18、7.5-1000

&Number of vertical and horizontal feed rates：64

&Bed saddle moves quickly：4000mm/min

&Maximum lateral travel of the lower tool holder:390mm

&Maximum stroke of upper tool hoider：200mm

&Tail socket diameter：Ф100mm

&Tail seat sleeve stroke：250mm

&Tailstock sleave tapered hole：Mohs6

&Main motor power：11KW

&Fast motor power：1.1KW

&Bed guide rail width：550mm

&Machine weiaht：4000kg

&Machine tool contour dimensions：4100*1400*1575
