CW6180(550Rail)

Technical parameter

Swing over bed：800mm

Maximum rotation diameter of the tool holder：520mm

Maximum workpiece length：2000/3000mm

Maximum turning length：1850/2850mm

Main spindle inner hole diameter：Ф105

Spindle hole front end taper：120#

Top taper：Mohs6

Range of speed levets：18、7.5-1000

Number of vertical and horizontal feed rates：64

Bed saddle moves quickly：4000mm/min

Maximum lateral travel of the lower tool holder:390mm

Maximum stroke of upper tool hoider：200mm

Tail socket diameter：Ф100mm

Tail seat sleeve stroke：250mm

Tailstock sleave tapered hole：Mohs6

Main motor power：11KW

Fast motor power：1.1KW

Bed guide rail width：550mm

Machine weiaht：3500kg

Machine tool contour dimensions：3600*1400*1575
