CA6140

Technical parameter

&Swing over bed:400mm

&Maximum workpiece length (distance between tvo tips):1000mm

&Maximum turning length (maxirum machining length):850

&Tumning diameter on the tool holder:210mm

&Distance from spindle canter to bed plane guide rail:205mm

&Main spindle through-hole dlameter:52mm

&Soindle hole front and tapar:Morse Cone number six

&Spindle speed level:forword24/reversal12

&Spindle speed range:10-1600(50HZ)/14-1580(50HZ)

&Type of longitudinal feed range:64

&Longitudinal feed range -standard feed:0.08-1.59mm

&Longitudinal feed range -smaall feed:0.028-0.054mm

&Longitudinal feed range - increase feed:1.71-6.33

&Types of cross feed range:64

&Cross feed range -standard feed:0.04-0.79mm

&Cross feed range -small feed:0.014-0.027mm

7Cross feed range-increase feed:0.86-3.16mm

&The fast longitedinal movement speed of the tool helder ：4m/min

&The fast lateral movement speed of the tool helder ：2m/min

&Maximumn travet ofupper/lower tool bolder (travel ofsmall toclholder/tnvel ofhorizontal tool hoider)：140

&Rotation angle of toot bolder turntable:±90°

&Cross section size ofthe tool holder (cross section of the square toolbolder toct holder)：25×25mm

&Cross section size ofthe tool holder (cross section of the square toolbolder toct holder)：26mm

&Bed tail spindle diameter (tail seat sleeve diameter)：75mm

&Bed tail spindleholetaper(tailstock seeve taper)：Morse Cone number five

&Maximum stroke of the spindle at the end ofthe bed：150mm

&Machine tool lead screw pitch：12mm

&Range and number ofmetric thread processing：44pcs；1-192

&Processing range and number ofimperial threads：20pcs；2-24

&Processing module thread range and variety：39pcs；0.25-48

&Range and number of processed radial pitch threads：37pcs；1-96

&Bed rail width (rail span)：400mm

&Hardness ofbed guide rail：RC52

&Main motor power:7.5KW

&Net wreight of machine tool:2400KG

&Machine tool outline dimensions (length x width xheight):2650×1150×1230mm
