C6240

Technical parameter

&Swing over bed:400mm

&Turning diameter inside the saddle:630

&Maximum workpiece length (distance between two tips)：1500

&Maximum turning length (maximum machining length)：1350

&Turning diameter on the tool holder：210

&Distance from spindle center to bed plane guide rail：205

&Main spindle through-hole diameter：82

&Spindle hole front end taper：Morse Cone number six

&Spindle speed level：forword24/reversal12

&Spindle speed range：12-1680(60HZ)/17-2000(60HZ)

&Type of longitudinal feed range：64

&Longitudinal feed range -standard feed:0.08-1.59mm

&Longitudinal feed range - small feed：0.028-0.054

&Longitudinal feed range - increase feed：1.71-6.33

&Types of cross feed range：64

&Cross feed range - standard feed：0.04-0.79mm

&Cross feed range - small feed：0.014-0.027

&Cross feed range -increase feed：0.86-3.16

&The fast longitedinal movement speed of the tool helder ：4m/min

&The fast lateral movement speed of the tool helder ：2m/min

&Maximumn travet ofupper/lower tool bolder (travel ofsmall toclholder/tnvel ofhorizontal tool hoider)：280

&Rotation anple oftool holder turntable;±90°

&Cross section size of the tool holder(cross section ofthe square toolholder tool holder)：25×25

&Distance from spindle centerine to tool support surface：26

&Bed tail spindle diameter (tail seat sleeve diameter)：75

&Bed tail spindle holetaper(taistock sleeve taper)：Morse Cone number five

&Maximum stroke ofthe spindle at the end of the bed:150mm

&Machine tool lead screwpitch：12mm

&Ranpe and number of metric thread processing：44pcs  1-192

&Processing range and numberofiperial threads:20pcs 2-24

&Processing module thread range and variety:39pcs 0.25-48

&Range and number ofprocessed radial pitch threads:37pcs 1-96

&Bed rail width (rail span):400mm

&Hardness ofbed guide rail:RC52

&Main motor power:7.5kw

&Net weight of machine tool:2600kg

&Machine tool outine dimensions (length x width x height):3150*1150*1230mm
