C6132

Technical parameter

&Max. workpiece turning diameter on the bed：320mm

&Max, workpiece turning dilameter on the tool holder：750mm

&Maximum workpiece rotation diameter on the tool holder：190mm

&Through-hole diameter：46mm

&Conical hole：MT6 u

&Speed 50HZ (60HZ)：25-1600r/min 12 级

&Maxmum lateral travel of the tool holder：240mm

&Maximum travel of the small knife holder：140mm

&Vertical scale value：0.5mrn/ r  100mm/r

&Horizontal knife holder scale value：0.05mm/r  4mm/r

&Scale value of small knife holder：0.05mm/r  3mm/r

&Distance from spindie centerine to tool support surface：22mm

&Knife bar cross-sectional dimension (height x width)：20mm×20mm

&Longitudinat feed rate：0.04-2.16mm/r 138

&Cross feed rate：0.02-1.08mm/r 138

&The maximum distance from the centerline of the spindleto the side of the square tool holder：205mm

&The taper of the inner hole of the top sleeve：MT4

&Maximum movement of the top cover:130mm

&Metric system：0.45-20 mm/r 30

&Imperial system：80-13/4 nn"

&Modulus：0.25-10mm 25

&Radiat pitch：160-31/2DP  30

&Main motor：YD132M-8/4 B5 TH 3/4.5 KW

&Cooling pump motor：AYB-20TH 0.115KW

&Extemnal dimensions:1900/2150x900x1200

&Machine weiaht:1400
